Benchmarking IO with FIO

This is a quick tldr there are many other situations and options you could consider

• FIO man page
• IOP/s = Input or Output operations per second
• Throughput = How many MB/s can you read/write continuously

Variables worth tuning based on your situation

• --iodepth

The iodepth is very dependant on your hardware.

• Rotational drives without much cache and high latency (i.e. desktop SATA drives) will not benefit from a large iodepth, Values between 16 to 64 could be sensible.

• High speed, lower latency SSDs (especially NVMe devices) can utilise a much higher iodepth, Values between 256 to 4096 could be sensible.

• --bs

The block size is very dependant on your workload.

• Writing/Reading lots of small files (i.e. documents, logs) benefit from / represent a smaller block size, Values between 2K - 128K could be sensible and 4k is likely the average in most situations.

• Writing/Reading large files (i.e. videos, database backups) benefit from / represent a large block size, Values between 2M - 8M could be sensible and 4M is likely the average in most situations.

Before running these tests

1. Check you’re in a directory with enough free disk space.
2. Check / pause any other workloads that may interfere with the results.
3. Understand your workload / what you intend to use the storage for - i.e. what matters?
4. Tune anything you might want to tune as above such as iodepth or size.

Random write test for IOP/s

i.e. lots of small files

sync;fio --randrepeat=1 --ioengine=libaio --direct=1 --gtod_reduce=1 --name=test --filename=test --bs=4k --iodepth=64 --size=4G --readwrite=randwrite --ramp_time=4

Random Read test for IOP/s

i.e. lots of small files

sync;fio --randrepeat=1 --ioengine=libaio --direct=1 --gtod_reduce=1 --name=test --filename=test --bs=4k --iodepth=64 --size=4G --readwrite=randread --ramp_time=4

Sequential write test for throughput

i.e. one large file

sync;fio --randrepeat=1 --ioengine=libaio --direct=1 --gtod_reduce=1 --name=test --filename=test --bs=4M --iodepth=64 --size=4G --readwrite=write --ramp_time=4

Sequential Read test for throughput

i.e. one large file

sync;fio --randrepeat=1 --ioengine=libaio --direct=1 --gtod_reduce=1 --name=test --filename=test --bs=4M --iodepth=64 --size=4G --readwrite=read --ramp_time=4

Testing IO latency without fio

samm@int-backup-01:/mnt/store1  # ioping . # old backup server
4096 bytes from . (ext4 /dev/mapper/store1-36TB): request=1 time=0.2 ms
4096 bytes from . (ext4 /dev/mapper/store1-36TB): request=2 time=0.1 ms
4096 bytes from . (ext4 /dev/mapper/store1-36TB): request=3 time=0.9 ms

vs

samm@int-backup-02:/mnt/store1  # ioping . # new backup server
4 KiB from . (ext4 /dev/md10): request=1 time=88 us
4 KiB from . (ext4 /dev/md10): request=2 time=103 us
4 KiB from . (ext4 /dev/md10): request=3 time=102 us
